POS MV WaveMaster II General Product Description: POS MV WaveMaster is a user-friendly, turnkey system designed and built to provide accurate attitude, heading, heave.
General Product Name: POS MV WaveMaster II Product Description: POS MV WaveMaster is a user-friendly, turnkey system designed and built to provide accurate attitude, heading, heave, position, and velocity data of your marine vessel and onboard sensors. POS MV is proven in all conditions, and is the georeferencing and motion compensation solution of choice for the hydrographic professional. Type of application: Year of initial development: 1994 Height m: 0.09 Width m: 0.165 Length m: 0.281 Weight kg: 3 Min. Voltage (AC): 110 Max.
Voltage (AC): 230 Min. Voltage (DC): 24 Max. Voltage (DC): 24 Power consumption W: 60 Splashproof casting: Y Water resistant casting: Y Water resistance m: Mean time between failures hr: Type of accelerometer: Type of gyro: Removable from base plate: Y Moving parts: Environmental Non-operating shock tolerance g: 320 Operating shock tolerance g: 90 Min. Operating temperature C: 0 Max. Operating temperature C: 55 Max. Rotation speed deg/s: Data formats NMEA formats: GGA; GST; HDT; ZDA; GGK; VTG; PASHR; PRDID; UTC; RMC; GSA; GSV RTCM: Y Other: CMR / CMR +; Ethernet (UDP / TCP) GNSS Positioning Sensor Number of integrated GNSS receivers and antenna ports: No.
Pos Mv Manual
Wavemaster Ii
Channels p receiver: Tracked satellite signals: SBAS differential signals: RTK Network Compatibility: Update rate Hz : Cold start seconds : Hot start seconds : GNSS positional accuracy Horizontal Position Accuracy RMS in cm : Horizontal Position Accuracy (SBAS) RMS in cm : Horizontal Position Accuracy (RTK) RMS in cm : GNSS aided uncertainty Heading deg: 0.015 Pitch deg: 0.02 Roll deg: 0.02 Heave: constant part m: 0.05 Heave: variable part %: 5 Surge/sway m: Increase in position uncertainty w.r.t.
